Blue car shade for 1 car

Our modern car shade is practical,durable and protect car from sun and rain.In additon,Membrane structure carport is a work of art,it gives people visual enjoyment and the curve shape of hardness with softness makes people's eyes shine and long aftertaste.


Share

PRODUCT FEATURES

Product Overviews:


Dimension:3100mm x 5950mm(width x length)

Yellow single carport for 1 car

Materials:Roof cover is PVDF membrane
Roof structure is Aluminium
Column and beam is hot galvanizing steel
Weight:320kg(350kg with package)
Package:Plywood case
Anti-wind10 grade(100km/h)
Anti-snow75kg/sq.m
Fire ResistanceDIN4102 B1/M2
Life span15-20 years
Labour3 persons
Time of installation    2-3 hours
ColorYellow,Gray,Blue,White,Brown,White,etc
Container loading 40units/20ft,75units/40ft


Material introductions:


1. Materials of roof cover

Roof cover of this carport is made of 1150g/sq.m high density polyethylene fabric coated with PVDF (Polyvinylidine Fluoride) at surface.It is high quality at waterproof,flame retardant,UV resistant,heat insulating and will not sag,fade,rot or mildew.The temperature resistance(℃) is from -40℃ to +70℃ and the life span is at least 15 years.Color options:Yellow,Gray,Blue,White,Brown,White,etc

Yellow single carport for 1 carYellow single carport for 1 car



2. Materials of roof structure

The roof frame to attach the PVDF membrane is made of aluminium(6061-T6).

Yellow single carport for 1 car

Yellow single carport for 1 car

Yellow single carport for 1 carYellow single carport for 1 carYellow single carport for 1 car


3. Materials of Column and Beam

It is made of Q235 steel,and we use the best surface treatment process for the steel---electrostatic powder spraying and hot galvanizing,it is high quality at resistance to corrosion and oxidation,also will be not fade.Color options:Black,White,Brown,Green,etc

Yellow single carport for 1 carYellow single carport for 1 carYellow single carport for 1 car
Yellow single carport for 1 carYellow single carport for 1 carYellow single carport for 1 car


Resistance of our carports to Wind and Snow load(Please contact us to get the TEST REPORT):

  1. Wind Load
    Our carport are not only the beautiful apprearance,but has also been designed to withstand the extreme climate,especcilly is the typhoon and heavy snow.It can withstand 100-120km/h Wind Speed.Besides,we also supply the expand screws for you to fix carport on the ground very well.

  2. Snow Load
    Our carport is well designed against the heavy snow.There are 6-8 aluminium pipes on the roof to support the heavy snow.Snow load exceed 0.3KN/sqm(50kg/sq.m and thickness of snow at 40-50cm).

Yellow single carport for 1 car

Yellow single carport for 1 carYellow single carport for 1 car


Guarantee of Our Carports:

We have quality control team who have strict quality control on all raw material. We ensure each part of carport will be in the highest quality.

The warranty of our carport is 5 years,if you have quality problem you need submit detail instruction and send clear photos for us in 7 days after you receive the product,then we will deal with the problem in 15 days.If the structure or cover of our carports has quality problem,we can send the new parts for free to you to replace.If it is damaged by your local people,we will offer to you at our lowest cost price.

Yellow single carport for 1 car

Packaging & Shipping:

The carports will be packed in wooden case to avoid something missing or damage in the transport process.Please see the package size and weight as follows.

ItemCarport sizePacking sizePacking weight       20ft container
Single carport5.95(L)x3.1(W)m2.9x0.58x0.43m350kg40units
Double carport5.95(L)x6.0(W)m2.9x0.58x0.50m500kg32units
Triple carport5.95(L)x9.0(W)m2.9x0.58x0.65m650kg24units
Carport for 4cars

5.95(L)x10.0(W)m

5.95(L)x12.0(W)m

2.9x0.58x0.75m

2.9x0.58x0.80m

750kg

800kg

24units

24units

Yellow single carport for 1 carYellow single carport for 1 carYellow single carport for 1 car


Installation of our carports:

It is not difficult to install this carport.We will offer detail installation Manul(documents and video) to you to study.
