Economical Awning
Optional iron front bar ,more economical.
Promotional and economical type.
There are two steel cables in the center joint of arms.
Double use motor available.
Ceiling & wall bracket available.
Standard arm shoulder is cast steel material,while Alu material arm shoulder is available.
PRODUCT FEATURES
Product Description:
Features:
1. Promotional and economical model.
2. Optional iron front bar,more econnomical.
3. There are two steel cables in the center joint of arms.
4. Double use motor available.
5. Standard arm shoulder is cast steel material ,while Alu material arm support is available.
6. Certificated: GS.CE,RoHs
Description:
Name : Promotional Economical Retractable Awning
Fabric type : 280gsm Polyester(or Acrylic)+PU Coating
Fabric color : Any Color
Frame color : RAL9010(Milk White), PC0102(Grey), PG3314(Black), PG0102(Grey)
Awning Data:
Max. size: 395*250cm
Min. size: 120*60cm
Cassette: No
Torsion Bar : 35*35mm
Roller: Φ60mm
Front Bar: 47*35mm
Support Arms: 47*28mm ,37*20mm
Gear Box: 1:7
Option Function:
1. Operation:
a) Manual operated by crank
b) Motorized avialble
2. Fabric: Polyester or Acrylic
3. Bracket: Standard:Wall bracket Optional:Ceiling and Wall bracket
4. Adjustable angle: 5-45 degree
5. Arm shoulder: standard is cast steel material, while Alu material arm shoulder is available
